5.9.4 Standard Seat Hanger depth adjustment
•
Remove both sets of 5mm hanger depth adjustment
bolts, (Fig.5.45).
•
Slide both hanger receivers to the desired location,
(Fig.5.46, inset B).
•
Replace both sets of depth adjustment bolts,
(Fig.5.47).
•
Use 20 N/m or 177 in/lb of torque.
Fig. 5.45
Fig. 5.47
28
SALSA M
2
Mini
Fig. 5.46
Rev.1.0
