Fig.13.9
Fig.13.10
Fig.13.11
64
SALSA M
2
Mini
13.4 Removing the castor wheel
WARNING!
Castor wheel removal is a safety critical task. If you do not
feel confident in carrying out the following instructions,
please contact your Sunrise Medical Approved Dealer.
•
Use two 13mm spanners to undo axle bolt (fig 13.12)
•
remove nyloc nut.
•
Withdraw bolt taking care to capture washers located
•
on each side of castor wheel (fig 13.13).
•
Remove castor wheel.
•
To refit, reverse above procedure taking care not to
•
force bolt through bearing spacer.
•
Gently move the wheel back and forth until bolt slips
through.
•
Tighten to a torque of 19Nm.
Fig.13.12
Fig.13.13
Rev.1.0
