9.4 Centre bar mount control (R-net)
WARNING!
•
Make sure that the controller is fixed securely to the
centre bar.
•
Always turn off the power to the controller before
moving the controller out of the way.
9.5 Tray mount control (R-net)
WARNING!
•
The maximum weight allowed for the tray is 2.5kg.
•
Do not overload the tray; this could cause the tray
to break or could cause the wheelchair to become
unstable.
•
Always turn off the power to the controller before
moving the tray out of the way.
•
Do not leave lit cigarettes or other heat sources on
the tray as this could cause the tray to deform and
mark.
•
Ensure that all extremities and clothing are free
when positioning the tray for use.
•
Ensure that you always have comfortable access
to the controls whilst the wheelchair is moving and
make sure that there is nothing on the tray that could
interfere with your control of the wheelchair.
9.6 Swing-away tray mounted centre control (R-net)
The swing-away tray mounted centre control enables the
hand control to be flipped over, providing a flat surface
when the tray is required and back around when the
user requires access to the hand control
NOTE: All warnings for the flip up version are the same
as the normal version (section 10.4 above) with the
following additional warnings:
WARNING!
•
Make sure that the controller is turned off before it is
flipped over
NOTE: Be aware that when the controller is flipped to
the underside of the tray that driving will be inhibited for
the user's safety.
Centre bar mount with R-net Control
Please refer to the R-net Owner's Manual for
details of R-net hand control functions.
48
SALSA M
2
Mini
9.7 Forus control (R-net)
WARNINGS!
•
Ensure that you set the speed of the forus control to a
speed that you can comfortably follow.
•
Ensure that you always have comfortable access to the
controls whilst the wheelchair is moving and make sure
that the controller is fixed securely to the wheelchair.
•
It is important that the joystick boot is replaced if it is
torn or brittle; failing to do so could cause substance
damage to the controller and unexpected movement of
the wheelchair.
•
Always turn off the power to the controller when leaving
the user in the wheelchair.
•
Do not replace the joystick knob with any unauthorised
item. It may cause hazardous operation and loss of
control of the wheelchair.
•
Do not hang any items on the handles of the forus
control.
The forus attendant control is a mechanical device that
translates mechanical attendant movements into joystick
movements on a regular remote control. (Fig 10.3)
The forus attendant control operates with R-net controls
only.
Forus with R-net Control
Please refer to the R-net Owner's Manual for
details of R-net hand control functions.
After switching on the hand control, the forus attendant
control is ready to use. Pushing the handle downwards
drives the wheelchair backwards, pushing the handle
upwards drives the wheelchair forwards. A left or right push
drives the wheelchair in the respective direction.
Emergency
stop button
Fig. 10.3
Adjustment
knob
Rev.1.0
