Delete All Recordings; Pings Per Second; Playback Speed - Humminbird HELIX 5 SERIES Operation Manual

Delete All Recordings allows you to delete all the recordings at once. This menu option is only
available when an optional-purchase microSD card is installed and Snapshot and Recording View
is on the screen.
Pings Per Second allows you to specify the ping rate for an active sonar recording.
NOTE: Pings Per Second is available when an optional-purchase microSD card is installed, Snapshot
and Recording View is on the screen, and the control head is actively recording (not playing back).
Auto is the default setting for Pings Per Second and automatically adjusts the ping rate for best
recording quality. If there is limited memory on your microSD card, you can slow the ping rate by
setting the Pings Per Second manually, but the recording will capture less sonar detail. For
maximum performance, keep the Pings Per Second setting on Auto.
Playback Speed allows you to specify the playback speed for a sonar recording from the Snapshot
and Recording View. This menu option is only available when an optional-purchase microSD card
is installed and Recording Playback is active.
Playback Speed Icons:
NOTE: You can also change playback speed in the Snapshot and Recording View using the LEFT and RIGHT
Cursor keys, although you cannot skip to the beginning or end of a recording using these keys.
Snapshot and Recording X-Press Menu

Delete All Recordings

(optional-purchase microSD Card, Snapshot and Recording View only)
Settings: Press the RIGHT Cursor key and follow screen instructions.

Pings Per Second

(optional-purchase microSD Card, Snapshot and Recording View only)
Settings: 1 to 10, Auto; Default = Auto

Playback Speed

(optional-purchase microSD Card, Snapshot and Recording View only)
Settings: Record, Rewind1, Rewind2, Slow Play Reverse, Pause, Slow
Play, Normal Play, Fast Forward1, Fast Forward2, Stop
Record
Rewind, Reverse
Rewind2
Slow Play Reverse
Pause
Slow Play
Normal Play
Fast Forward
Fast Forward2
Stop
90
