Humminbird HELIX 5 SERIES Operation Manual page 47

1
2
3
4
5
1
Depth
2
Water Surface Temperature
3
Voltage
4
Triplog
5
Speed
NOTE: To change the colors used to display the Down Imaging data on the screen, see Down Imaging
X-Press Menu: DI Colors.
Down Imaging View with Active Cursor and Zoom
6
7
8
41
9
Cursor Dialog Information 6
Zoom Magnification Box 7
Zoomed View 8
Lower Range 9
Sonar Views
