■ Others set screen (continued)
SPEECH [MODE] Switch
Turns the operating mode announcement ON or OFF.
• OFF: The operating mode is announced.
• ON: The operating mode is announcer when the
mode is changed.
Memo Pad Quantity
Sets the number of memo pad channels.
• 5: 5 channels.
• 10: 10 channels.
MAIN DIAL Operation
Selects [MAIN DIAL] operating mode.
• MAIN: The only Main band frequency can be
set by rotating [MAIN DIAL].
• MAIN/SUB: The Sub band frequency can be also
set by rotating [MAIN DIAL] when the
Sub band is selected.

MAIN DIAL Auto TS

Sets the Automatic Tuning Step function for [MAIN
DIAL].
When rapidly rotating [MAIN DIAL], the tuning step
is automatically changed according to the rotation
speed.
• OFF: Turn OFF the function.
• LOW: Tuning step is automatically changed in the
low step.
• HIGH: Tuning step is automatically changed in the
high step.
SUB DIAL Auto TS
Sets the Automatic Tuning Step function for [SUB
DIAL].
When rapidly rotating [SUB DIAL], the tuning step
is automatically changed according to the rotation
speed.
• OFF: Turn OFF the function.
• LOW: Tuning step is automatically changed in the
low step.
• HIGH: Tuning step is automatically changed in the
high step.
(Default: OFF)
(Default: 5)
(Default: MAIN/SUB)
(Default: HIGH)
(Default: HIGH)
15-15
MAIN/SUB Tracking [MAIN] SW
Assigns the Main/Sub band tracking function to the
[MAIN] key.
• OFF: The [MAIN] key does not act as the Tracking
function key.
• ON: Hold down the [MAIN] key for 1 second to turn
the function ON or OFF.
• Hold down the [SUB] key for 1 second also turns
the function OFF.
• In the tracking mode, rotate [MAIN DIAL] changes
the MAIN and SUB bands' frequencies.
Rotate [SUB DIAL] to change only the SUB band
frequency.
MIC Up/Down Speed
Sets the response speed of [UP]/[DN] on the optional
microphone.
• LOW: Slow.
• HIGH: Fast.
Quick RIT/∂TX Clear
Selects the operation of [CLEAR] for the RIT/
function.
• OFF: Hold down [CLEAR] for 1 second to clear.
• ON: Push [CLEAR] to clear.
[NOTCH] Switch (SSB)
Selects the notch function for the SSB mode.
• Auto: Auto notch.
• Manual: Manual notch.
• Auto/Manual: Auto notch and manual notch can be
toggled.
[NOTCH] Switch (AM)
Selects the notch function for the AM mode.
• Auto: Auto notch.
• Manual: Manual notch.
• Auto/Manual: Auto notch and manual notch can be
toggled.
DIGI-SEL VR Operation
Selects the function assigned to [DIGI-SEL].
• DIGI-SEL: Used for the digital selector adjustment.
• APF: Used for the audio peak filter adjust-
ment.
15
SET MODE
(Default: OFF)
(Default: HIGH)
(Default: OFF)
∂
TX
(Default: Auto/Manual)
(Default: Auto/Manual)
(Default: DIGI-SEL)
