Icom IC-7850 Instruction Manual page 217

15
SET MODE
■ ACC set screen
ACC-A AF/SQL Output Select
Selects the audio and squelch signals to output from
[A ACC1] (Audio: pin 5, Squelch: pin 6) between the
Main and Sub bands.
• MAIN: Main band's AF and squelch signals are out-
put from [A ACC1].
• SUB: Sub band's AF and squelch signals are output
from [A ACC1].
ACC-B AF/SQL Output Select
Selects the audio and squelch signals to output from
[B ACC1] (Audio: pin 5, Squelch: pin 6) between the
Main and Sub bands.
• MAIN: Main band's audio and squelch signals are
output from [B ACC1].
• SUB: Sub band's audio and squelch signals are
output from [B ACC1].
ACC-A Output Select
Selects the signal output from [A ACC1].
• AF: AF signal is output from [A ACC1].
• IF: A 12 kHz IF signal is output from [A ACC1].
ACC-A AF/IF XFC Output (SPLIT ON)
Selects the signal output from [A ACC1] while [XFC] is
held down in the split operation.
• MAIN: Main band's AF/IF signal.
• SUB: Sub band's AF/IF signal.
• When "MAIN" is selected, the Sub band audio is muted.
• When "SUB" is selected, the Main band audio is muted.
• Setting the [ACC-A AF SQL Output Select] item is neces-
sary.
ACC-A AF Output Level
Sets the AF output level of [A ACC1].
• Range: 0%–100% (in 1% steps)
• Approximately 200 mV at the 50% (default) setting.
ACC-A AF SQL
Select the squelch behavior of [A ACC1].
• OFF(OPEN): The squelch is always opened regard-
less of the transceiver's squelch con-
dition.
• ON: The squelch opens and closes, ac-
cording to the transceiver's squelch
condition.
(Default: MAIN)
(Default: SUB)
(Default: AF)
(Default: SUB)
(Default: 50%)
(Default: OFF(OPEN))
ACC-A AF Beep/Speech... Output
Sets the Beep and Speech audio output condition. ([A
ACC1])
• OFF: Beep and Speech audio are not output from [A
ACC1].
• ON: Beep and Speech audio are output from [A
ACC1].
• Setting the [ACC-A AF SQL Output Select] item is neces-
sary.
• The beep level is limited when the [Beep Level Limit] is
ON.
• The side tone level is limited when the [Side Tone Level
Limit] is ON.
ACC-A IF Output Level
Sets the IF output level of [A ACC1].
• Range: 0%–100% (in 1% steps)
ACC-B Output Select
Selects the signal output from [B ACC1].
• AF: AF signal is output from [B ACC1].
• IF: IF signal is output from [B ACC1].
ACC-B AF/IF XFC Output (SPLIT ON)
Selects the signal output from [B ACC1] while [XFC] is
held down in the split operation.
• MAIN: Main band's AF/IF signal.
• SUB: Sub band's AF/IF signal.
• When "MAIN" is selected, the Sub band audio is muted.
• When "SUB" is selected, the Main band audio is muted.
• Setting the [ACC-B AF SQL Output Select] item is neces-
sary.
ACC-B AF Output Level
Sets the AF output level of [B ACC1], within 0 to 100%
in 1% steps.
• At 50%, the output level is approximately 200 mV.
ACC-B AF SQL
Select the squelch behavior of [B ACC1].
• OFF(OPEN): The squelch is always opened regard-
less of the transceiver's squelch con-
dition.
•ON: The squelch opens and closes, ac-
cording to the transceiver's squelch
condition.
15-6
(Default: OFF)
(Default: 50%)
(Default: AF)
(Default: SUB)
(Default: 50%)
(Default: OFF(OPEN))
