• Offset frequency settings
Command : 1A 050114, 050115, 050120
q w
X 0 X
*No need to enter for transverter offset frequency setting.
† Transverter offset only, fix to '0' for split offset setting.
• Color settings
Command : 1A 050189, 050190, 050191, 050257,
050266, 050267, 050268, 050269,
050274, 050279, 050280, 050281,
050282, 050289, 050291
q w e
0 X X X 0
R (Red)
0000–0255
• Bandscope edge frequency settings
Command: 1A 050198~050233
q w e
X 0 X X X X X
Lower edge
• Data mode with filter width settings
Command : 1A 06
q w
X X X X
* When "00" is set, set "00" in w
e r*
X X X XX
r t y
X X X 0 X X X
G (Green) B (Blue)
0000–0255 0000–0255
r t y
0 X X X X
Higher edge
00=Data mode OFF
01=FIL1
02=FIL2
03=FIL3
00=Data mode OFF*
01=Data mode 1 (D1)
02=Data mode 2 (D2)
03=Data mode 3 (D3)
• Codes for the memory name, opening message,
NTP server address, CLOCK2 name, network
name, and network radio name contents
- Character codes— Letters
Character ASCII code
A–Z
- Character codes— Symbols
Character ASCII code
!
$
&
?
'
^
−
/
,
;
<
(
[
{
|
¯
Command
1A 00 Memory name
All characters are usable.
1A 050094 Opening message
Upper case letters, numbers, some symbols (−
/ . @) and space are usable.
1A 050098 NTP server address
Upper and lower case letters, numbers, and
some symbols ( . _ ) are usable.
1A 050102 CLOCK2 name
All characters are usable.
1A 05 0175 Network name
Upper case letters, numbers, and some
symbols (! # $ % & " ` ^ + – . , ; = ( ) [ ] { } _ ¯
@) are usable.
1A 05 0181 Network radio name
Upper and lower case letters, numbers, some
symbols (! # $ % & ? " ' ` ^ + – ✱ / . , : ; = < > (
) [ ] { } ¦ _ ¯ @) and space are usable.
• RX HPF/LPF setting for each operating mode
Command : 1A 050001, 050004, 050007, 050010,
050011, 050012
HPF
00: Through
01~20: 100~2000 Hz
*The value of the HPF should be smaller than the LPF.
