NEC Express5800 User Manual page 77

Figure 4-24. Securing the hard Disk Drive
13. Position the hard disk drive cage into the system. The four tabs on the top of
the hard disk drive cage insert into the four slots located on the bottom of the
floppy disk drive cage. See Figure 4-25.
Figure 4-25. Installing a Hard Disk Drive Cage
Hold the hard disk cage securely to avoid touching
components on the system board.
14. Secure the hard disk bracket with the four screws removed in step 7.
15. Install the fan removed in step 6 into the hard disk cage. See Figure 4-26.
! CAUTION
Upgrading Your System 4-23
