9. Remove the disk drive from its protective wrapper and place it on an
antistatic surface. Record the drive model and serial number in the
equipment log.
10. Set any drive jumpers or switches before you install the drive. See the
documentation that comes with the device for jumper or switch information.
11. Insert the hard disk drive into the drive cage with the board surface facing
the bottom. See Figure 4-22.
Note:
varies depending on the type of the drive.
Install the first IDE hard disk drive in the top bay of the hard
disk bracket. Install the second IDE hard disk drive in the
third bay from the top. See Figure 4-23.
Figure 4-23. Position of IDE Hard Disk Drives in the Cage
12. Secure the hard disk drive in the hard disk drive cage with the four screws
supplied. See Figure 4-24.
4-22 Upgrading Your System
Figure 4-22. Installing a Hard Disk Drive
The installation of a hard disk drive in the server
