Specifications

3.1 F-201B
Spezifikation
Image Device
Effective Picture Elements
Lens Mount
Picture Sizes
Cell Size
ADC
Data Path
Frame-Rates
Gain Control
Shutter Speed
External Trigger
Shutter
Internal Memory
# Look Up Tables
Smart Functions
Transfer Rate
Digital Interface
Power Requirements
Power Consumption
Dimensions
Mass
Operating Temperature
Storage Temperature
Regulations
Options
The design and specifications for the product described may change without notice.
1/1,8" Type progressive scan b/w SONY IT CCD
1628 (H) x 1236 (V)
C-Mount
640 x 480 Pixel (Format_0; Mode_5 )
800 x 600 Pixel (Format_1; Mode_2)
1024 x 768 ((Format_1; Mode_5)
1280 x 960 (Format_2; Mode_2)
1600 x 1200 (Format_2; Mode_5)
1628 x 1236 (Format_7; Mode_0)
814 x 1236 (Format_7 ; Mode_1), horizontal binning
1628 x 618 (Format_7; Mode_2), vertical binning
814 x 618 (Format_7; Mode_5), h + v binning
4,4 µm x 4,4 µm; (8,8 µm x 8,8 µm in h + v binning)
12 Bit
8 Bit
1,875 Hz; 3,75 Hz; 7,5 Hz; 15 Hz; External Trigger Shutter
Manual 0 – 24 dB (0,035 dB/step)
1-4095 x Timebase
Timebase: 1, 2, 5, 20, 50, 100, 200, 500, 1000µs
Trigger Mode_0
Advanced feature: Image Transfer by command
15 frames
Up to 63, user programmable (12Bit -> 8 Bit); Gamma (0,45)
2 x 2 Binning; Real Time Shading-Correction; Image
Sequencing, three configurable inputs, three configurable
outputs
400 Mb/s
IEEE 1394 IIDC v1.3
DC 8V – 36V via IEEE 1394 cable or 12-pin HIROSE
Less than 3,5 Watt (at 12V DC)
115mm x 45mm x 45mm (L x W x H); w/o tripod and lens
230 gr (without lens)
+ 5 - 45 ° Celsius
-10 - 60 ° Celsius
EN 55022; EN 61000-6-2;FCC Class A
Removable IR-Cut-Filter, Host Adapter Card, API
(FirePackage)
