Interpolation (BAYER demosaicing)
In interpolation a red, green or blue value is determined for each pixel. Only two lines
are used for this simple interpolation:
Input:
Output:
=
P 1 R
red
=
P 1
green
=
P 1 B
blue
Color cameras begin outputting the image in line two and finish in line Y (maximum
image height minus two). This is a side-effect of BAYER demosaicing. The adjustable
maximum image height is also two lines less than in the b/w variant.
Please note that on the color camera a black border one pixel wide forms on the
left and right image borders also as a consequence of BAYER demosaicing, because
the image width displayed on the color camera is not scaled down.
Color correction
Color correction is calculated along with YUV conversion and mapped via a matrix like
this.
=
*
red Crr
=
*
green
=
*
blue Crb
On the color camera color correction is also deactivated in Mono8 or Mono16 mode (raw
image transport).
