9.2.1

Advanced Feature Inquiry

The presence of each of the following features can be queried by the "0" bit of the
corresponding register.
Offset
0xF1000040
0xF1000044
0xF1000048
0xF100004C
9.2.2

MaxResolution

This register indicates the highest resolution for the sensor and is "read-only".
The register normally outputs the MAX_IMAGE_SIZE_INQ Format_7 Mode_0 value.
Offset
0xF1000200
9.2.3

Timebase

Corresponding to IIDC, exposure time is set via a 12-bit value in the corresponding
register (SHUTTER_INQ [51Ch] and SHUTTER [81Ch]).
This means that a value in the range of 1 to 4095 can be entered.
Dolphin cameras use a timebase which is multiplied by the shutter register value. This
multiplier is configured as the time base via the TIMEBASE register.
60
Name Field
ADV_INQ_1 MaxResolution
TimeBase
ExtdShutter
TestImage
---
Sequences
--
Lookup Tables
Shading
DeferredTrans
---
GP_Buffer
ADV_INQ_2 Input_1
Input_2
Input_3
---
Output_1
Output_2
Output_3
---
IntEnaDelay
IncDecoder
---
ADV_INQ_3 ---
ADV_INQ_4 ---
Name Field
MAX_RESOLUTION MaxHeight
MaxWidth
Bit Description
[0]
[1]
[2]
[3]
[4]
[5]
[6..7]
[8]
[9]
[10]
[11..30]
[31]
[0]
[1]
[2]
[3..7]
[8]
[9]
[10]
[11..15]
[16]
[17]
[18..31]
[0..31]
[0..31]
Bit Description
[0..15] Sensor height (rd only)
[16..31] Sensor width (rd only)
