Mono8 (raw data):
Figure 39 Bayer-coded test image
F-201C
The color camera outputs Bayer-coded raw data in Mono8 instead of – as described in
IIDC v. 1.3 – a real Y signal. The first pixel of the image is always the red pixel from the
senor.
