Thus, a maximum delay of 63.27 µs can occur.
FVal Zustand
low
high
Jitter at the beginning of exposure has no effect on the length of exposure time,
i.e. it is always constant.
7.9

Sequence mode

The camera enables certain image settings to be set differently for a succession of
images.
For a sequence of images with different lighting colors each image can be recorded with
a different gain to obtain the same brightness effect. The image area of a sequence of
images can automatically be separated into several smaller ones by varying the AOI.
A parameter set is stored in the camera for each image to be recorded. This sequence of
parameter sets is simply called a sequence.
The following registers can be used to effect the individual steps of the sequence.
All modes
Fixed modes only
Format_7 only
7.9.1

How is sequence mode implemented?

There is a FIFO (first in first out) memory for each of the IIDC v. 1.3 registers listed
above. The depth of each FIFO is determined by the maximum number of images
contained in the sequence.
F-201B F-201C
100 ns 100 ns
63,27 µs 63,27 µs
Cur_V_Mode, Cur_V_Format, ISO_Channel, ISO_Speed, Brightness,
White_Balance (color cameras only), Shutter, Gain, Lookup- Table,
TestImage
Cur_V_Frm_Rate
Image_Position, Image_Size, Color_Coding_ID, Byte_Per_Packet,
Binning
35
