9.1.11

Video mode control and status registers for Format_7

The offset to the base address is in V_CSR_INQ_7_x. The offset entered 100h must be
added for Mode 1, 200h for Mode 2 200h and 300h for Mode 3.
Offset
000h
004h
008h
00Ch
010h
014h
034h
038h
03Ch
040h
044h
For all modes in Format_7 ErrorFlag_1 and ErrorFlag_2 are refreshed on each access
to the Format_7 Register.
Contrary to IIDC DCAM v. 1.3 registers relevant to Format_7 are refreshed on each
access. The "Setting_1" bit is automatically cleared after each access.
When ErrorFlag_1 or ErrorFlag_2 is set and Format_7 is configured, no image capture
is started.
Contrary to IIDC v.1.3 COLOR_CODING_ID is set to a default value after an
INITIALIZE or "reset".
Contrary to IIDC DCAM v.1.3 the UnitBytePerPacket field is already filled in with a
fixed value in the PACKET_PARA_INQ register.
9.2

Advanced features

The camera has a variety of extended features going beyond the possibilities described
in IIDC v. 1.3.
Advanced features should always be activated before accessing them.
The color and B/W models of the camera vary in the availability of some advanced
features.
Currently all registers can be written without being activated. This makes it easier to
operate the camera using "Directcontrol".
AVT reserves the right to require activation in future versions of the software.
Name
MAX_IMAGE_SIZE_INQ
UNIT_SIZE_INQ
IMAGE_POSITION
IMAGE_SIZE
COLOR_CODING_ID
COLOR_CODING_INQ
PIXEL_NUMER_INQ
TOTAL_BYTES_HI_INQ
TOTAL_BYTES_LO_INQ
PACKET_PARA_INQ
BYTE_PER_PACKET
Notes
See above
See above
See above
See above
See above
