SPITFIRE EP (40)
Requires: 5-channel radio w/ 5 mini servos,
Outrunner Motor KM374810,
w/ Propeller Adaptor HW2340102,
40A Brushless ESC with 11x8E proepller,
4 cells 14.8V 3200 mAh Li - Po battery & charger.
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this
kind of electric powered precision model. Operating this model without prior preparation may
cause injuries. Remember, safety is the most important thing. Always keep this instruction
manual at hand for quick reference.
The World Models
Manufacturing Co., Ltd.
www.theworldmodels.com
450W Motor System
Specifications
*Specifications are subject to change without notice.*
50 in / 1270 mm
446.4 sq in / 28.8 sq dm
3.6 Ib / 1640 g
42 in / 1065 mm
ALMOST-READY-TO-FLY (ARF) SERIES
INSTRUCTION MANUAL
FACTORY PRE-FABRICATED
MADE IN CHINA
Advertisement
Table of Contents
Related Manuals for THE WORLD MODELS SPITFIRE EP
Summary of Contents for THE WORLD MODELS SPITFIRE EP
- Page 1 INSTRUCTION MANUAL SPITFIRE EP (40) 450W Motor System Requires: 5-channel radio w/ 5 mini servos, Outrunner Motor KM374810, w/ Propeller Adaptor HW2340102, 40A Brushless ESC with 11x8E proepller, 4 cells 14.8V 3200 mAh Li - Po battery & charger. Specifications...
-
Page 2: Before You Begin
SPITFIRE EP (40) I N D E X BEFORE YOU BEGIN P. 1 P. 2 PARTS LIST P.3-P.11 ASSEMBLY SAFETY PRECAUTIONS P.11 BEFORE YOU BEGIN Read through the manual before you begin, so you will have an overall idea of what to do. -
Page 3: Parts List
Parts List 1. MAIN WING -- 1 pair 10.SOCKET HEAD SCREW M3x12mm -- 4 pcs SCREW PWA2.3x8mm -- 4 pcs 2. PLYWOOD 2x48x48mm (For Aileron Servo) -- 1 pair BALSA 7x8x13mm (For Aileron Servo Stand) -- 4 pcs WASHER d3xD7mm -- 4 pcs PUSHROD Ø1.4x70mm w/ Threads (For Aileron) -- 2 pcs COWLING -- 1 pc. -
Page 4: Aileron Servo
Aileron Apply instant type CA glue to both sides of each hinge. Bottom View Ø1mm pilot holes for World Models horn are pre-drilled. Aileron Servo Please look for pin-hole marks at under side of control surfaces. PA1.7x8mm Screw Balsa Wood PA1.7x8mm 7x8x13mm Screw... - Page 5 Main Wing and Retract Servo Please dry fit wing joiner into left and right wing to make sure they fit with the proper dihedral angle, mark the wing joiner if necessary. Apply epoxy glue to both sides of all surfaces in contact. Use a stick to apply the glue to inner side of wing joiner sleeve, and apply the glue to wing joiner before putting them together.
-
Page 6: Stabilizer & Elevator
Apply instant type CA glue to both sides of each Stabilizer & Elevator hinge. (Stabi l i zer) (Mai n Wi ng) B=B' A=A' Temporary install the main wing, adjust leveling of the stabilizer to make it as parallel to the main wing as possible. -
Page 7: Tail Landing Gear
Tail Landing Gear PA2.6x12mm Screw PA2.6x12mm PM2x10mm Screw M2 Nut set screw 2.1mm Collar M2 Nut Steering Bracket Bottom View PM2x10mm Ø1mm pilot holes for World Models horn are pre-drilled. Elevator Pushrod Please look for pin-hole marks at under side of control surfaces. PB2x10mm Screw TWM PL8210010 CLEVIS WRENCH... - Page 8 Outrunner Motor / Cowling / Spinner Motor Mount Optional Parts M3x12mm Socket Head Screw PL5404000 Outrunner 37/48 Deluxe d3xD7mm Washer KM0374810 Propeller Adaptor Set Make sure the rotating HW2340102 PWA2.3x8mm Screw motor casing is not in contact with wirings or Propeller Set (11x8E) anything.
-
Page 9: Radio Equipment
Radio Equipment Install and arrange the servo as shown in the diagram. Elevator Pushrod J1(Pushrod Ø1.4x42mm) Ø1.4x42mm Pushrod Connector J2(Pushrod Ø1.4x610mm) Elevator Servo KA1.7x6mm Front Rudder Servo Straper Rudder Pushrod Sponge10x50x150mm Fuel Tube Battery Tie Receiver Elevator Servo d2xD4x4mm 200mm Bottom View Battery Completed... - Page 10 Main Wing M2.5x30mm Socket Head Screw d2.5xD8mm Washer Wing Protection M2.5x30mm d2.5xD8mm Completed Canopy Pilot PWA2x8mm Screw PWA2x8mm...
- Page 11 Wing Setting Adjust the wing and fuselage configuration as shown in the diagrams. A’ B’ ’ ’ A=A’ B=B’ C=C’ D=D’ P.10...
-
Page 12: Control Throws
# Pre-flight adjustment must be done before flying, it is very dangerous to fly a badly pre-adjusted aircraft. SPITFIRE EP (40) is specially designed to be powered by 450W Motor System. # Make sure the air field is spacious, never fly the plane too close to people and never get too close to a running propeller. - Page 13 LINKAGE CONNECTOR HW7111050 & HW7111060 Drill 2mm hole at servo horn. Insert linkage connector into servo horn. Make sure shoulder of screw is cleared from servo horn. Add washer to reduce play if necessary. Shoulder Tighten up the round nut against the shoulder.
- Page 14 Product Registration Form (US Customers) We would like to share with you any relevant information regarding your model, including product news and free upgrade parts when applicable. Please fill in the following and send to AirBorne Models, 4749-K, Bennett Drive, Livermore, CA 94551 USA. 1.
- Page 15 Pl8210010 Large Clevis • Small Clevis • HW2340102 d5xD6 1 set Outrunner 37 / 48 Deluxe HW3111700 KM0374810 KC2040A02 55x28x12mm 1 pc. -Max speed: 13860 rpm -Kv (rpm / V): 770 -Operating Power: 450 W -Operating Voltage: 8.5 - 18 V -Operating Current: 30 A -Peak Current: 30A (max.
- Page 16 Ｐａｔｔｅｒｎ Ｄｕｃｔｅｄ Ｆａｎ Ｆｕｎｆｌｙ Ｗａｒｂｉｒｄｓ Ｓｃａｌｅ Ｅｌｅｃｔｒｉｃ Ｓｐｏｒｔｓ Ｇｌｉｄｅｒ Ｂｏａｔ Ｔｒａｉｎｅｒ Ａｃｃｅｓｓｏｒｉｅｓ Ｃｏｖｅｒｉｎｇ （Ｌｉｇｈｔｅｘ ／ Ｔｏｕｇｈｌｏｎ） The World Models Manufacturing Co., Ltd. www.theworldmodels.com E311XMPO21100907...
