Radio Equipment
Install and arrange the servo as shown in the diagram.
Elevator Pushrod
J1(Pushrod Ø1.4x42mm)
Ø1.4x42mm
J1
Pushrod Connector
J2
J2(Pushrod Ø1.4x610mm)
Elevator Servo
KA1.7x6mm
Front
Rudder Servo
Straper
Rudder Pushrod
Sponge10x50x150mm
Fuel Tube
Battery Tie
Receiver
Elevator Servo
d2xD4x4mm
200mm
Bottom View
Battery
Completed
