Aileron Servo; Stabilizer & Elevator - THE WORLD MODELS VOODOO MUSTANG EP Instruction Manual

4

Aileron Servo

PB2x16mm Screw
4
PA1.7x8mm Screw
8
Ø1mm pilot holes for World
Models tri-horn are pre-drilled.
Please look for pin-hole marks
at under side of control surfaces.
02L
03L
04L
Please choose either 02L & 02R or 03L & 03R or 04L & 04R that suits your servo.
5
Stabilizer & Elevator
PB2x8mm Screw
2
A A'
Temporary install the main wing, adjust leveling
of the stabilizer to make it as parallel to the
main wing as possible.
A=A'
Apply instant type CA glue to both sides of each hinge.
E230RXMPO26791108
02R
03R
04R
TWM PL8210010
CLEVIS WRENCH
(Stabi l i zer)
B B'
(Mai n Wi ng)
B=B'
Fuel Tube
Straper
d2xD4x4mm
Bottom View
Balsa 3.5x13.2x35mm
PB2x8mm
P.4
PA1.7x8mm
PA1.7x8mm
Completed
