MIDGET MUSTANG
0.61 cu.in. displacement 2-cycle
0.91 cu.in. displacement 4-cycle
Radio required : 4 - channels radio w/ 5 standard servos
Wing Span
Wing Area
Flying Weight
Fuselage Length
Warning ! This model is not a toy.
It is designed for maximum performance. Please seek advice if one is not familiar with this kind
of engine powered precision model. Operating this model without prior preparation may cause
injuries. Remember, safety is the most important thing. Always keep this instruction manual
at hand for quick reference.
The World Models
Manufacturing Co., LTD.
www .thew orldm odels .com
Specifications
* Specifications are subject to change without notice.*
INSTRUCTION MANUAL
59.5 in / 1510 mm
667 sq in / 43.0 sq dm
7.5 lbs / 3400 g
51.0 in / 1290 mm
ALMOST-READY-TO-FLY (ARF) SERIES
FACTORY PRE-FABRICATED
MADE IN CHINA
