Aileron Servo - THE WORLD MODELS Zero Fighter 60S Instruction Manual

1 Main Wing
Aileron Servo Lead
2
Retractable Langing Gear
Set Screw
3mm
2
Collar
4.1mm
2
Screw
KA3x14mm
8
3

Aileron Servo

Screw
PWA2 x 8mm
8
Aileron Servo Cover
2x58x71mm
All manuals and user guides at all-guides.com
PWA2x8mm
2mm
Bottom View
Peel off shaded portion
covering film
Bottom View
3mm Set Screw
Bottom View
Balsa Wood
8x8x21mm
1mm
P.3
Pre-glued
KA3x14mm
1mm
1mm
Peel off shaded
Portion covering
film.
