1
Main Wing
2
Retractable Landing Gear
Bottom View
3
Retract Servo
To L-Side
Wheels Down Position
16mm
Travel
Wheels Up Position
E230RXMPO26791108
Apply instant type CA glue to both sides of each hinge.
Please refer to attached sheet for linkage connector installation.
To R-Side
16mm
Travel
Aileron Servo Lead
Bottom View
Aileron Servo Lead
Linkage connector
P.3
