Aileron Servo - THE WORLD MODELS PIPER J-3 CUB 26s Instruction Manual

Main Wing
1
2 Main Wing

Aileron Servo

3
A002SPO24781009
Apply instant type CA glue to both sides of each hinge.
Please dry fit wing joiner into left and right wing to make sure they fit with the proper
dihedral angle, mark the wing joiner if necessary. Apply epoxy glue to both sides of
all surfaces in contact. Use a stick to apply the glue to inner side of wing joiner
sleeve, and apply the glue to wing joiner before putting them together. Wing joiner
not glued properly will lead to wing failure and plane crash.
Wing joiner
6x20x87mm
Straper
Fuel Tube
Ø6x5mm
Pushrod
Ø1 . 8x100mm
P.3
Balsa
5x8x20mm
1mm
Clevis
Ring
