Installation
1-Gang Mount Box
Monitor
(if required, not supplied)
Mounting
Bracket
Monitor
Surface mount the bracket of the monitor or if
required onto a 1-gang mount box (not supplied).
Make the system connections to the back of the
monitor as per below and then slide the monitor onto
Site the indoor monitor to suit application.
the bracket using the hooks to hold firmly in place.
Rear View of Monitor
System
Connections
BUS
Connect a normally open switch to
trigger the monitor's door bell facility
SD card slot (32GB Max.)
Records visitor images
