Parts List - THE WORLD MODELS FUN WORLD 40 Instruction Manual

Parts List

1. MAIN WING -- 1 pair
2. SCREW PB2x12mm -- 4 pcs
CLEVIS -- 2 pcs
STRAPER -- 2 pcs
FUEL TUBE Ø6x5mm -- 4 pcs
HORN -- 2 sets
PUSHROD Ø1.8x125mm w/ Threads (For Aileron) -- 2 pcs
PLYWOOD 2x24x46mm (For mini servo stand) -- 2 pcs
3. STABILIZER & ELEVATOR -- 1 set
FUSELAGE -- 1 pc.
4. VERTICAL FIN & RUDDER -- 1 set
5. SCREW PM2x6mm -- 4 pcs
SCREW PM2x12mm -- 6 pcs
WASHER d2xD5mm -- 6 pcs
M2 NUT -- 6 pcs
FLYING WIRE BRACKET -- 6 pcs
FLYING WIRE BRACKET CLEVIS -- 4 pcs
EYE SCREW M1.8x8x19.5mm -- 4 pcs
WIRE Ø1x600mm -- 1 pc.
COPPER TUBE d2.5xD3.2x8mm -- 6 pcs
6. TAIL LANDING GEAR -- 1 set
WHEEL Ø23mm -- 1 pc.
SCREW PA2.6x12mm -- 2 pcs
SCREW PM2x10mm -- 1 pc.
M2 NUT -- 1 pc.
COLLAR Ø2.1mm w/ set screw -- 1 set
PLATE 0.3mm -- 1 pc.
7. SCREW PB2x12mm -- 4 pcs
CLEVIS -- 2 pcs
HORN -- 2 sets
FUEL TUBE Ø6x5mm -- 2 pcs
PUSHROD Ø1.8x560mm w/ Threads (For Elevator) -- 2 pcs
8. SCREW PB2x10mm -- 2 pcs
CLEVIS -- 1 pc.
HORN -- 1 set
FUEL TUBE d5xD6mm -- 1 pc.
PUSHROD Ø1.8x645mm w/ Threads (For Rudder) -- 1 pc.
10. COWLING -- 1 pc.
TRANSPARENT DUMMY COWLING -- 1 pc.
SCREW PWA2.6x12mm -- 4 pcs
SILICON GROMMET d1.5xD6.5mm -- 4 pcs
SPINNER Ø52mm -- 1 set
11. MAIN LANDING GEAR -- 1 pc.
WHEEL Ø50mm -- 2 pcs
SCREW PA2x10mm -- 6 pcs
COLLAR Ø3.1mm w/ set screw -- 4 sets
LANDING WIRE STRAPS (PL4114030) -- 3 pcs
12. CANOPY -- 1 pc.
SCREW PWA2.3x8mm -- 4 pcs
SILICON GROMMET d1.5xD6.5mm -- 4 pcs
DOUBLE-SIDED TAPE 6x620mm -- 1 pc
13. EYE SCREW PA2.5x10x23mm -- 2 pcs
WING TUBE Ø14.5x324mm -- 1 pc.
RUBBER BAND D30x1mm -- 2 pcs
14. SCREW PWA2x8mm -- 6 pcs
STRAPER -- 2 pcs
FUEL TUBE Ø6x5mm -- 2 pcs
PLYWOOD 2x72x260.2mm -- 1 pc.
PLYWOOD 2x72x122mm (For mini servo stand) -- 1 pc.
SPONGE 10x80x200mm -- 2 pcs
PUSHROD Ø1.8x80mm (For Elevator) -- 1 pc.
PUSHROD CONNECTOR (For Elevator) -- 1 set
15. DECALS:A262SDEC -- 1 set
COVERING:--
LIGHTEX SGX 250 BLUE
LIGHTEX SGX 030 TRANSPARENT YELLOW
LIGHTEX SGX 330 CADMIUM YELLOW
LIGHTEX SGX 571 RICH GOLD
P.2
