Radio Equipment - THE WORLD MODELS FUN WORLD 40 Instruction Manual

14

Radio Equipment

PWA2x8mm Screw
6
Front
Plywood
2x72x122mm
J1(Pushrod Ø1.8x80mm)
J2(Pushrod Ø1.8x560mm)
Front
Sponge
10x80x200mm
Bottom View
Sponge
Front
10x80x200mm
PWA2x8mm
1mm
Bottom View
Install and arrange the servo as shown in the diagram.
Pushrod Connector
Elevator Servo
Fuel Tube
Receiver
Ø6x5mm
Straper
Throttle Pushwire
Throttle Servo
Ø1.2x400mm
Receiver
Plywood 2x72x260.2mm
If you choose mini servo, please add
this step.
Bottom View
Elevator Pushrod
Ø1.8x80mm
M2 Nut
Rudder Servo
Elevator Servo
Rudder Pushrod
Fuel Tube
Ø1.8x645mm
Ø6x5mm
Straper
Elevator Servo
Rudder Servo
P.10
Completed
A
Nitro Powered
KM2x8mm
Rudder Pushrod
Ø1.8x645mm
Elevator Pushrod
Ø1.8x560mm
B
Electric Powered
Elevator Pushrod
Ø1.8x560mm
Completed
