THE WORLD MODELS FUN WORLD 40 Instruction Manual page 7

9 A
Engine
This step is for engine powered. Please follow
step 9B if your model is electric powered.
To complete your Fun world 40 (nitro powered),
you need to purchase The World Models A262SGPTS.
Apply thread locker to screws.
Blind nuts are off-centered to keep the spinner at the
fuselage axis.
d3xD7mm
Washer
M3x20mm
Socket Head Screw
Engine Mount
PL5111030
M3x25mm
d3xD7mm
Washer
Fuel Tank
200cc
UP
M3 Nut
Plastic Tube
d2xD3x220mm
P.6
Optional parts for nitro powered
Fun world 40, A262SGPTS.
Fuel Tank
260cc
Plywood
8x8x76mm
Balsa 8x8x76mm
(For Fuel Tank Position Fixing)
Fuel Tank
260cc
Installed Engine Position
105 mm
4.13in.
Bottom View
Throttle Servo
Linkage Connector
Throttle Pushrod
Ø1.2x400mm
A262SGPTS
Bottom View
