Parts List

1. MAIN WING -- 1 pair
2. SERVO MOUNTING PANEL (For Aileron) -- 2 pairs
HEAVY DUTY CLEVIS PL4112200 -- 8 sets
SCREW PM4x60mm -- 4 pcs
SCREW PWA2x8mm -- 16 pcs
M4 NYLON INSERT LOCK NUT -- 4 pcs
HEAVY DUTY HORN BRACKET PL4112400 -- 4 sets
HEAVY DUTY SERVO HORN PL4120300 -- 4 sets
PUSHROD M3xD5x83mm w/ Threads (For Aileron) -- 4 pcs
SWIVEL CLEVIS HORN FAIRING PL4610010 -- 4 sets
3. FUSELAGE -- 1 pc.
STABILIZER & ELEVATOR -- 1 set
SCREW PA3x12mm -- 2 pcs
WASHER d3xD7mm -- 2 pcs
STABILIZER TUBE D18x509mm -- 1 pc.
4. VERTICAL FIN & RUDDER -- 1 set
5. TAIL GEAR ASSEMELY (PL3410022) --1 set
SCREW PA3.5x16mm -- 3 pcs
SCREW PWA2.5x12mm -- 3 pcs
6. MAIN LANDING GEAR -- 1 set
AXLE SHAFT Ø5x50mm -- 2 pcs
SCREW PM3x15mm -- 4 pcs
SOCKET HEAD SCREW M5x20mm -- 4 pcs
M8 NYLON INSERT LOCK NUT -- 2 pcs
WASHER d5xD12mm -- 4 pcs
WASHER d3xD7mm -- 4 pcs
COLLAR Ø5.2mm w/ set screw -- 4 sets
WHEEL Ø102mm -- 2 pcs
WHEEL PANTS -- 1 pair
7. SERVO MOUNTING PANEL (For Rudder) -- 1 pair
HEAVY DUTY CLEVIS PL4112200 -- 8 sets
HEAVY DUTY HORN BRACKET PL4112400 -- 2 sets
HEAVY DUTY SERVO HORN PL4120300 -- 2 sets
HEAVY DUTY SERVO HORN PL4120600 -- 1 set
HEAVY DUTY SERVO HORN PL4120800BB -- 1 set
PUSHROD M3xD5x137mm w/ Threads (For Rudder) -- 2 pcs
SWIVEL CLEVIS HORN FAIRING PL4610020 -- 1 set
SCREW M4x128mm -- 1 pc.
SCREW M3x35mm -- 2 pcs
M4 NYLON INSERT LOCK NUT -- 2 pcs
EYE SCREW M2.5x8x25mm -- 4 pcs
WIRE Ø1x1100mm (For Rudder) -- 2 pcs
COPPER TUBE d2.5xD3.2x8mm -- 4 pcs
SWIVEL CLEVIS HORN SUPPORT -- 1 set
SCREW PM2.5x35mm -- 1 pc.
M2.5 NYLON INSERT LOCK NUT -- 1 pc.
SCREW PWA2x8mm -- 8 pcs
8. SERVO MOUNTING PANEL (For Elevator) -- 1 pair
HEAVY DUTY CLEVIS PL4112200 -- 4 sets
HEAVY DUTY HORN BRACKET PL4112400 -- 2 sets
HEAVY DUTY SERVO HORN PL4120300 -- 2 sets
PUSHROD M3x40mm w/ Threads (For Elevator) -- 2 pcs
SWIVEL CLEVIS HORN FAIRING PL4610010 -- 2 sets
SCREW PM4x60mm -- 2 pcs
M4 NYLON INSERT LOCK NUT -- 2 pcs
SCREW PWA2x8mm -- 8 pcs
9. FUEL TANK 1500cc (PL1121500G-gasoline) -- 1 set
CABLE TIE (For Fuel Tank) -- 2 pcs
10. BLIND NUT M6 -- 4 pcs
WASHER d6xD15mm -- 4 pcs
SOCKET HEAD SCREW M6x50mm -- 4 pcs
SCREW PWA2x12mm -- 4 pcs
SCREW PWA2.6x12mm -- 4 pcs
PLYWOOD 2x106x155mm -- 1 pc.
PLYWOOD 3x106x156mm -- 1 pc.
THROTTLE PUSHWIRE Ø1.2x450mm -- 1 pc.
PLASTIC TUBE d2xD3x350mm -- 1 pc.
LINKAGE CONNECTOR Ø2.1mm -- 1 set
11. SPONGE 10x80x200mm -- 2 pcs
12. WING TUBE D38x1064mm -- 1 pc.
SCREW PM3x35mm -- 1 pc.
SCREW PA3x35mm -- 1 pc.
WASHER d3xD7mm -- 2 pcs
13. CANOPY -- 1 pc.
SCREW PM3x18mm -- 4 pcs
WASHER d3xD7mm -- 4 pcs
SCREW PWA2.3x12mm -- 7 pcs
SILICON GROMMET d1.5xD6.5mm -- 7 pcs
PILOT PC10110A -- 1 set
14. COWLING -- 1 pc.
TRANSPARENT 3D TEMPLATE -- 1 pc.
SCREW PA3x12mm -- 6 pcs
WASHER d3xD7mm -- 6 pcs
SILICON GROMMET d2.5xD8.5mm -- 6 pcs
SPINNER (with. aluminum. back plate) Ø102mm -- 1 set
15. DECALS A181DEC -- 1 set
COVERING:--
TOUGHLON STL100 WHITE
TOUGHLON STL 250 BLUE
TOUGHLON STL 312 BRIGHT RED
TOUGHLON STL 331 CUB YELLOW
