13
Canopy
PM3x18mm Screw
4
d3xD7mm Washer
4
PWA2.3x12mm Screw
7
d1.5xD6.5mm Silicon Grommet
7
14
Cowling & Spinner
PA3x12mm Screw
6
d3xD7mm Washer
6
d2.5xD8.5mm Silicon Grommet
6
Please refer to the
attached sheet for
usage of the
transparent 3D
template.
First insert the grommet to the canopy then apply screw.
PILOT PC10110A
PM3x18mm
d3xD7mm
Washer
First insert the grommet to the cowling then apply screw.
Spinner
Ø102mm
2mm
1.5mm
P.10
PWA2.3x12mm
d1.5xD6.5mm Silicon Grommet
PM3x18mm
d3xD7mm Washer
PA3x12mm
d2.5xD8.5mm Silicon Grommet
