Raisecom
MSG1200 (A) User Manual
Model Speed
(Gbit/s)
USFP- 1.25
Gb/SS35-
D-R
Optical modules whose models have the SS letters are single-fiber SFP modules,
such as the USFP-03/SS35-D-R. These SFP optical modules must be used in pair,
which means that the Tx wavelength of the sender SFP optical module must be
consistent with the Tx wavelength of the receiver SFP optical module, and vice versa.
For example, the USFP-03/SS13-D-R and USFP-03/SS15-D-R should work together.
Rx Tx
wavel wavel optical
ength ength Power
(nm) (nm) (dBm)
1550 1450– -2 to 3
1510
Raisecom Technology Co., Ltd.
Tx Rx Mo
sensiti de
vity
(dBm)
< -30 SM
1 Product overview
Transm Interf
ission ace
distanc
e (km)
80 LC/PC Supp
orted
Single-
fiber
bidirec
tional
DD RoHS
M
Compli
ant
7
