Page 1: User Manual
ISCOM 1005M(A) User Manual Raisecom Technology Co., Ltd . Dec, 2005... -
Page 2: Table Of Contents
3. Parameters ........................4 3.1 Features: ......................4 3.2 Specifications: .....................5 3.3 Environment and power: ..................5 4. Mechanical structure and indicators................5 5. How to manage ISCOM 1005M(A)................6 5.1 Manual overview....................6 5.2 Configure ISCOM 1005M(A) ................7 5.2.1 Log on ......................7 5.2.2 PORT SETUP...................7 5.2.3Port VLAN Setting ..................8... -
Page 3: Cautions
User manual 1. Cautions Please read the following notice carefully before installing and using the device, Raisecom shall not be responsible for any loss that caused by violating safety notice. ISCOM1005M(A) is integrated device that has precise elements, please avoid violent shakes and impacts, and do not disassemble or maintain the device yourself. -
Page 4: Iscom 1005M(A) Overview
User manual 2. ISCOM 1005M(A) Overview ISCOM 1005M(A) is 5-port Ethernet switch complied with 802.1Q VLAN and supports Console local management and traffic, bandwidth management. 2.1Package 1 unit ISCOM 1005M(A) 1 piece DC 5V power cord 1 piece CBL-RS232-DB9F/RJ45-A-2m connection cable 3. -
Page 5: Specifications
Environment Temp:０~５０ centigrade Humidity: 5% ~ 95% Power consumption: く 5W Power: 100-240VAC，50-60Hz 4. Mechanical structure and indicators LEDs provide all of information and status of interface of Ethernet switch. ISCOM 1005M LNK/ACT 100M 1 2 3 状态 条件 Fixed on... -
Page 6: How To Manage Iscom 1005M(A)
Ethernet switch can be managed via VT100 terminal or computer workstation through CONSLE cable. ISCOM 1005M(A)’s default setting as [bits per second: 9600, data bits: 8, Parity: 0, stop bits: 1, flow control: None], VT100 type terminal. Log on ISCOM 1005M(A) -
Page 7: Configure Iscom 1005M(A)
User manual 5.2 Configure ISCOM 1005M(A) 5.2.1 Log on Input “1234” at first time. Then management screen will available. P.S: the command is only available for lowercase. Press ”ESC” to return main manual Choose the item through numeric key on this interface. -
Page 8: 3Port Vlan Setting
User manual Modify setting Press “m” to modify the setting including：Admin(e：open，d：close)、Auto(e： auto negotiation， d： non auto negotiation)、 speed (1： 100M， 0： 10M)、 Duplex(f： full，h：half)、flow-C(e：enable flow control，d：disable flow control). After modification, press “y” to save, press “n” not to save. Download Ingress、upload Egress bandwidth management N x 32Kbps，N is configurable. -
Page 9: Tag Vlan Setting
User manual Select “2”: the system will ask user to manually configure each VLAN according the specific requirement. Select “3”: remove all of the VLAN 5.2.4 TAG VLAN setting P.S: before creating 802.1Q VLAN group, Port VLAN must be removed firstly. Select “3”... - Page 10 User manual select “2” to modify VLAN domain. Input “m” to access the dialog interface to modify VLAN domain and select GroupNo: “1” (only 0～15 VLAN Group. Select the GroupNo, not VLANID. Now try to select GroupNo.1) and select Add or Remove Port and select Port No.
-
Page 11: 5Modify Password
User manual Select “4” to configure the tag of port. “TAGGED PORT” can not be connected to “UNTAGGED PORT” of the subscriber. 5.2.5Modify password Choose “4-Password Setup” to modify the password. 5.2.6Advanced setting Choose “5” to access “Advanced Setup”. -
Page 12: 7Restore Default Setting
User manual If the function of filtering broadcast storm is available, these broadcast packets will be disregarded with 50ms when broadcast packets is over threshold. The customer can configure 3 types for threshold (based on port) 1: 10% for all of interfaces; 2: 20% for all of interfaces;... -
Page 13: Troubleshooting
User manual 6. Troubleshooting 6.1 How to resolve the link LED off The possible reasons as followings: 1.the power supply is off 2.the type of the cable is not right 3.the interface of Ethernet switch is trouble 6.2 Q&A 1. -
Page 14: Cable Types And Function
User manual white-gree ----------------- RX+ white-gree green ----------------- green white-oran ----------------- white-oran blue ----------------- blue white-blue ----------------- white-blue orange ----------------- orange white-brow ----------------- white-brow brown ----------------- brown Standard cross over line Hub /switch Pin # Pin# white-gree ---- ---- RX+ white-oran Green ---- ----... - Page 15 User manual Green ----------------- White- ----------------- orange Blue ----------------- unavailable GND White – ----------------- blue Orange ----------------- unavailable GND White-bro ----------------- unavailable Brown ----------------- unavailable ----------------- unavailable...
