Netopia R2020 User Reference Manual page 33

When the test is successful, you will see the
Manual or Automated Connection Profile screen. The
SmartStart Wizard asks you to select a method of
creating a connection profile. The connection profile tells
your router how to communicate with your ISP or other
remote site, such as your corporate office. You can select
either ISP Automation or Manual Entry.
Options are explained below.
Make your selection and click Next.
If you select ISP Automation, SmartStart offers you the option of choosing one of several Netopia ISP
partners that support the Netopia R2020. You then see the
page 3-5.
If you select Manual Entry, you must be prepared with the following information. You must enter:
Your dial-up number, sometimes referred to as an ISP POP number
Your Login name and Password. (These are case-sensitive.)
Any PBX or Centrex phone system dialing prefix (such as "9" for an outside line)
Your PPP authentication method. Options are: PAP (Password Authentication Protocol), CHAP (Challenge
Handshake Authentication Protocol), or None. Most ISPs use PAP; this is the default.
Your Domain Name Server (DNS); this entry must be an IP address in dotted decimal format. (for example,
192.168.4.10, not "joe.isp.com")
Optionally, an alternate DNS if your ISP provided one
If you select Manual Entry, the
appears.
Internet Service Provider Selection screen. Select an
ISP from the list of Netopia ISP partners who have
provided information for automatic setup. Choose
Generic ISP if your ISP is not included on the list. If you
don't already have an account with the selected ISP, call
and order service using the listed customer service
telephone number.
When you have done this, click Next.
Most ISPs will provide you with information for you to enter in the
over the phone using the toll-free phone number shown in the scrolling list. Generally, they will provide you
Setting up your Router with the SmartStart Wizard 3-5
"Manual or Automated Connection Profile screen,"
"Connection Profile screen,"
"Internet Service Provider Selection screen" on
shown "Connection Profile screen" on page 3-6
"Connection Profile screen" on page 3-6
shown below.
