Main Landing Gear - THE WORLD MODELS Delta Jet EP Instruction Manual

5
Vertical Fin & Rudder
Apply instant type CA glue to both sides of
each hinge.
6

Main Landing Gear

PA2.3x8mm Screw
8
2.6mm Collar
4
2.6mm Collar
3mm Set Screw
Intercooler Air Exit
Completed
Ø1mm pilot hole is pre-drilled. Please look for
pin-hole marks at under side of wing.
PA2.3x8mm
P.6
A
A=A'
Mounting Plate
Bottom View
A'
12x27mm
