7
Front Landing Gear
PA2x8mm Screw
2
8
Rudder Pushrod
PB2x8mm Screw
Clevis
Horn
PB2x8mm
9
Main Wing
PM3x45mm Screw
2
d3xD7mm Washer
2
Ø1mm pilot hole is pre-drilled. Please look for
pin-hole marks at under side of fuselage.
Ø1mm pilot holes for World Models horn are pre-drilled. Please
look for pin-hole marks at under side of control surfaces.
2
Pushrod
Ø1.2x444mm
Fuel Tube
d2xD4x4mm
PM3x45mm
1.3mm
Bottom View
d3xD7mm
Belly Pan
Washer
Bottom View
P.7
Plastic Collar
d1.1xD5x2mm
PA2x8mm
Completed
Completed
