Mitsubishi Electric FR-D720-008 Instruction Manual page 197

(7) Setting items and set data
After completion of parameter settings, set the instruction codes and data then start communication from the computer to
allow various types of operation control and monitoring.
No. Item
1 Operation mode
Output
frequency
/speed
Output
current
Output
voltage
Special
monitor
2
Special
monitor
Selection No.
Fault
description
Run command
(expansion)
3
Run command
Inverter status
monitor
4
(expansion)
Inverter status
monitor
Set frequency
(RAM)
Set frequency
(EEPROM)
Set frequency
5
(RAM)
Set frequency
(RAM, EEPROM)
Refer to page 187 for data format (A, A1, A2, A3, B, C, C1, D, E, E1, E2, E3)
Instruction
Read/
Write Code
H0000: Network operation
Read H7B
H0001: External operation
Write HFB
H0002: PU operation
H0000 to HFFFF: Output frequency in 0.01Hz increments
Speed increments 1/0.001 (when Pr. 37 = 0.01 to 9998)
When "0.01 to 9998" is set in Pr. 37 and "01" in instruction code
Read H6F HFF, the increments change to 0.001 and the data format is E2.
When "100" is set in Pr. 52, the monitor value is different
depending on whether the inverter is at a stop or running.
(Refer to page 126)
H0000 to HFFFF: Output current (hexadecimal) in 0.01A
Read H70
increments
H0000 to HFFFF: Output voltage (hexadecimal) in 0.1V
Read H71
increments
H0000 to HFFFF: Monitor data selected in instruction code HF3
Read H72 When "0.01 to 9998" is set in Pr. 37 and "01" in instruction code
HFF, the data format is E2.
Read H73
H01 to H40: Monitor selection data
Refer to the special monitor No. table (page 195)
Write HF3
H0000 to HFFFF: Two latest fault definitions
Read H74 to H77
Refer to the alarm data table (page 196)
Write HF9
Control input commands such as forward rotation signal (STF)
and reverse rotation signal (STR). (For details, refer to page 196)
Write HFA
Monitor the states of the output signals such as forward rotation,
Read H79
reverse rotation and inverter running (RUN). (For details, refer to
page 196)
Read H7A
Read set frequency/speed from RAM or EEPROM.
H6D
H0000 to HFFFF: Set frequency in 0.01Hz increments
Read Speed increments 1/0.001 (when Pr. 37 = 0.01 to 9998)
H6E
When "0.01 to 9998" is set in Pr. 37 and "01" in instruction code
HFF, the increments change to 0.001 and the data format is E2.
Write set frequency/speed to RAM or EEPROM.
HED
H0000 to H9C40 (0 to 400.00Hz): Frequency increments 0.01Hz
Speed increments 1/0.001 (when Pr. 37 = 0.01 to 9998)
Write When "0.01 to 9998" is set in Pr. 37 and "01" in instruction code
HFF, the increments change to 0.001 and the data format is A2.
HEE
To change the set frequency consecutively, write data to the
inverter RAM. (instruction code: HED)
Communication operation and setting
Data Definition
b15 b8b7
First fault in past Latest fault
H74
Third fault in past Second fault in past
H75
Fifth fault in past Fourth fault in past
H76
Seventh fault in past Sixth fault in past
H77
Number of
Data Digits
(Format)
4 digits
(B, E/D)
4 digits
(A, C/D)
4 digits
(B, E/D),
6 digits
(B, E2/D)
4 digits
(B, E/D)
4 digits
(B, E/D)
4 digits
(B, E/D),
6 digits
(B, E2/D)
2 digits
(B, E1/D)
2 digits
(A1, C/D)
b0
4 digits
(B, E/D)
4 digits
(A, C/D)
2 digits
(A1, C/D)
4 digits
(B, E/D)
2 digits
(B, E1/D)
4 digits
(B, E/D),
6 digits
(B, E2/D)
4 digits
(A, C/D),
6 digits
(A2, C/D)
193
4
