NETWORK MENU (continued)
ITEM
HUB LINK SETTING
NETWORK SCALE
SNMP
IPSEC
FTP
TELNET
WEB
GATEWAY ADDRESS
SUBNET MASK
IPV4 ADDRESS
IP ADDRESS
ETHERTALK
NETWARE
NETBIOS OVER TCP
NETBEUI
800.788.5572
SETTINGS
AUTO NEGOTIATE
100BASE-TX FULL
100BASE-TX HALF
10BASE-T FULL
10BASE-T HALF
NORMAL / SMALL
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
xxx.xxx.xxx.xxx
xxx.xxx.xxx.xxx
xxx.xxx.xxx.xxx
SET AUTO / MANUAL
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
DuraLabel.com
EXPLANATION
Sets full or half duplex for communication via a
network hub.
When AUTO is set, negotiation is done
automatically.
Selects network size.
When NORMAL is selected, printer can work
effectively, even when connected to a HUB that
has a spanning tree feature. However, printer
start up time gets longer when computers are
connected with two or three small LANs.
When SMALL is selected, computers can cover
from two or three small LANs to a large LAN, but
may not work effectively when connected to a
HUB that has a spanning tree feature.
Enables or disables SNMP protocol.
Sets Enable/Disable of IPSec. Enable via the
web.
Enable: IPSec is available.
Disable: IPSec is not available.
Enables or disables communication via FTP.
Enables or disables Telnet config. facility.
Enables or disables Web config. facility.
Current assigned gateway address. To change,
proceed as above.
Current assigned subnet mask. To change,
proceed as above.
Current assigned IP address. To change, press
OK and use Menu buttons to increment 1st
octet, then press OK again to move on to next
octet. When 4th octet has been set, press OK
again to register new address.
Specifies whether IP address allocation is
automatic (DHCP) or manually assigned.
Enables or disables this network protocol.
Enables or disables this network protocol.
Sets Enable/Disable of NetBIOS over TCP
protocol.
Display Conditions:
> TCP/IP should be enabled.
> IP Version is not IPv6.
Enables or disables this network protocol.
Menu functions
41
