Menu functions
PPR EMULATION MENU (continued)
LINE LENGTH
LF FUNCTION
CR FUNCTION
WHITE PAGE SKIP
LINE PITCH
ZERO CHARACTER
LETTER 0 STYLE
SYMBOL SET
CHARACTER SET
FONT CONDENSE
PCL EMULATION
This menu controls settings effective when the printer is operating in PCL emulation
mode.
ITEM
FONT SOURCE
TRAY ID#
MP TRAY
TRAY 2
PEN WIDTH
ADJUST
TRUE BLACK
PRINT MARGIN
NORMAL
44
80 COLUMN; 136 COLUMN
LF / LF+CR
CR / CR+LF
OFF / ON
6 LPI; 8 LPI
NORMAL
SLASHED
DISABLE
ENABLE
IBM-437
(Default Symbol Set only shown)
SET-1
SET-2
12CPI TO 20CPI
12CPI TO 12CPI
SETTINGS
RESIDENT / RESIDENT2
1 ~ 4 ~ 59
1 ~ 5 ~ 59
ON/OFF
OFF / ON
1/5 INCH
1/6 INCH
Specifies the number of characters per line.
Selects whether a received line feed
character (0Ah) also causes a carriage
return.
Selects whether a received carriage return
character (0Dh) also causes a line feed.
Selects whether blank pages are printed
or not.
Specifies the line spacing.
Sets the zero to be slashed or unslashed.
Specifies the style that replaces 9BH with
letter o and 9DH with a zero
Specifies a symbol set.
Specifies a character set.
Specifies 12CPI pitch for Condense Mode.
EXPLANATION
Specifies the location of the PCL default font. Normally
this will be INTERNAL unless additional fonts are installed
in the expansion ROM slot or additional fonts have been
downloaded to RAM as permanent fonts.
Sets the # to specify the MP tray for the paper feed
destination command (ESC&l#H) in PCL5e emulation.
Sets the # to specify Tray 2 for the paper feed destination
command (ESC&l#H) in PCL5e emulation.
(Displayed only if Tray 2 is installed).
When minimum width is specified in PCL, sometimes a
1-dot line, looks broken.
With PEN WIDTH Adjust set to ON, when the minimum
width is specified, the line width will be emphasized so as
to look wider than a 1-dot line.
With PEN WIDTH Adjust set to OFF, the line will appear as
before.
Selects whether black image data is printed using black
toner (ON) or 100% CMY (OFF). (Valid in PCL emulation
mode only.)
Sets the non-printable page area. NORMAL is PCL
compatible.
