Menu functions
MAINTENANCE MENU (continued)
ITEM
AUTO PW OFF
SLEEP
POWER SAVE
SAVE MENU

NETWORK MENU

This menu controls the operation of the printer's 10Base-T/100Base-TX network
interface.
ITEM
TCP/IP
FACTORY DEFAULTS
TCP ACK
40
SETTINGS
ENABLE
AUTO CONFIG
DISABLE
ENABLE / DISABLE
ENABLE / DISABLE
EXECUTE
SETTINGS
ENABLE / DISABLE
EXECUTE
TYPE 1
TYPE2
EXPLANATION
ENABLE: When the printer is not used for a period of
time, it turns off the power automatically.
AUTO CONFIG: Auto power off is enabled, however, the
printer will not turn off the power under the following
conditions:
◦ An Ethernet cable is plugged to the network
interface connection.
Note: The default setting varies depending on the sales
area.
Sets Enable/Disable of Sleep Mode.
Enables or disables automatic power save mode.
Delay before entering this mode is set in the SYSTEM
CONFIGURATION menu.
Saves the current menu settings. The last menu
executed is saved and the menu previously saved is
overwritten and erased.
When you press the OK button, the following
confirmation message is displayed.
ARE YOU SURE? YES/NO
If you select NO, the display returns to the previous
menu.
If you select YES, the current menu settings are stored
and the menu is exited.
EXPLANATION
Enables or disables this network protocol.
Reloads the settings present when the unit was
setup by the manufacturer.
This setting determines whether the network
card in the Printer/MFP will acknowledge
every TCP packet or whether it will delay it's
acknowledgement until multiple packets have
been received.
When Type 1 is set the Printer/MFP will respond
to every TCP packet with an ACK packet.
When Type 2 is set the Printer/MFP will delay it's
TCP ACK response.
In most environments the default TCP ACK
setting should be OK, however changing this
setting may be beneficial when a connection
problem (e.g your printing job incompletely
terminates) occurs if it takes a long time to
interpret/print your job.
