Korg HAVIAN 30 User Manual page 339

Trigger Mode
Sound Controller 1
Sound Controller 2
Sound Controller Y+
Sound Controller Y-
Cycle 1
Cycle 2
Random
After Touch Trigger
On
Y+ Trigger On
Y- Trigger On
Legato Up
Setting the oscillator's basic parameters |335
Meaning
The Oscillator only plays when a CC#80 (Sound Controller 1) mes-
sage is received. Press and release the corresponding physical
controller, and the next note will also trigger the selected Oscillator.
If you keep it pressed, the Oscillator will continue to be triggered
until you release the controller.
Hint: This (like the following Sound Controllers) is especially useful
to enable a different nuance to the following note(s).
As the above, but with the CC#81 (Sound Controller 2) message.
As the above, but with the joystick, assigned as the Sound
Controller, pushed at least half-way forward (value 64). The con-
troller is turned off when the joystick is released. This control is
equivalent to a CC#01 (Modulation) Control Change message.
As the above, but with the joystick, assigned as the Sound
Controller, pulled at least half-way back (value 64). The controller
is turned off when the joystick is released. This control is equiva-
lent to a CC#02 (Breath Controller) Control Change message.
All Oscillators with this same trigger mode assigned will play in cy-
cle. For example, if Oscillators 1, 2 and 4 are assigned the Cycle
1 trigger mode, the following note will trigger Oscillator 1, then 2,
then 4, then 1 again.
Hint: This is especially useful to trigger different sound nuances or
create vector-like sound sequences.
As the above, for use with a different (and parallel) group of
Oscillators. Having two Cycle Trigger Modes allows for cycling
stereo multisamples.
As the above, but with a random selection of Oscillators within the
assigned group.
The Oscillator starts playing when an After Touch message with a
value of at least 90 is received. The Velocity value is the same as
the latest Note On message. The Oscillator will stop playing when
the After Touch value falls back to zero.
Hint: This (like the following Triggers) is especially useful to trigger
harmonics or growls when a note is already playing.
As the above, but with the joystick, assigned as the Sound
Controller, pushed at least half-way forward (value 64). The con-
troller is turned off when the joystick is released. This control is
equivalent to a CC#01 (Modulation) Control Change message.
As the above, but with the joystick, assigned as the Sound
Controller, pulled at least half-way back (value 64). The controller
is turned off when the joystick is released. This control is equiva-
lent to a CC#02 (Breath Controller) Control Change message.
Like Legato, but this is only activated when the second note is out
of the Max Range value (as set in the Basic > Sound Basic page)
and it is higher than the first one.
