Front Panel LEDs

Table 1 describes the front panel LEDs in order as located on the chassis from left to right.
LED
STATUS
POWER 1/POWER 2
DBU
LAN 1/LAN 2 TD/RD
LAN 1/LAN 2 LNK
STATUS (Slots 1 through 6)
ACTIVITY (Slots 1 through 6)
TEST (Slots 1 through 6)
18

Table 1. NetVanta 5305 LEDs

Color
Green (flashing) Unit is powering up.
Green (solid) Power is on, self-test passed.
Red (solid) Self-test failed or boot code could not be loaded.
Green Power supply is operational.
Red Power supply failed.
Off No power supply is present.
Off No dial backup modules are installed.
Green (solid) Dial backup module is ready for use.
Green (flashing) Unit is in dial backup.
Red (solid) Dial backup alarm condition exists.
Yellow (solid) The unit is in test.
Green (flashing) Activity on the Ethernet port.
Off No activity on the Ethernet port.
Green (solid) 10Base-T link is up.
Yellow (solid) 100Base-T link is up.
Red Link is down.
Off Link is administratively down.
Slot is empty, or the interface is administratively
Off
down.
Green (solid) Link is up.
Red (solid) Alarm condition is present on the module.
Green (flashing) Data is present on the module (i.e., for the T3
module, this indicates TD/RD data).
Off No activity on the module.
Off No test is running.
Yellow (solid) Module is in test.
Copyright © 2010 ADTRAN, Inc.
NetVanta 5305 Hardware Installation Guide
Indication
61200990L1-34N
