NetVanta 5305 Hardware Installation Guide
NetVanta Octal T1/E1 Wide Module
•
Octal T1/E1 Wide Module
•
Quick start guide
Option modules are intended to be serviced by qualified service personnel only.
2.
PRODUCT OVERVIEW
Reviewing the Front Panel Design
Figure 1
shows the NetVanta 5305 front panel.
Figure 1. NetVanta 5305 (AC and DC versions) Front Panel Layout
61200990L1-34N
Copyright © 2010 ADTRAN, Inc.
Product Overview
17
