NETVANTA 5305 CONTROLLER
Quick Start Guide
S
PECIFICATIONS
Interfaces: Console: EIA-232 (DB-9 female) for access to command line
interface and monitoring
Ethernet: Two 10/100BaseT interfaces (RJ-48C) for
connection to the local area network
Compliance: FCC Part 15, Class A, UL 60950/CSA-C22.2 No. 60950,
EN 60950, IEC 60950, AS/NZS 60950, EN 55022, EN 55024
Environmental: Operating Temperature: 0°C to 50°C
Storage Temperature: 20°C to 70°C
Relative Humidity: 95% non-condensing
I I
NSTALLATION NSTRUCTIONS
1. Remove the existing controller from the controller slot in the NetVanta 5305
Base Unit.
2. Slide the System Controller into the controller slot until the module is firmly
positioned in the chassis.
3. Secure the screws at both edges of the module. Tighten with a screwdriver.
4. Connect the cables to the associated device(s).
5. Complete the system installation as specified in the Hardware Installation
Guide (P/N 61200990L1-34).
Quick Start Guide, 61200831L1-13B, July 2004
E
Pin
1
2
3
4, 5
6
7, 8
C
Pin
1
2
3
4
5
6
7
8
9
Technical Support 1-888-4ADTRAN (1-888-423-8726)
For more detailed documentation, visit us online at
P
THERNET INOUT
Name
TX1
TX2
RX1
—
RX2
—
P
ONSOLE INOUT
Name
DCD
RD
TD
DTR
SG
DSR
RTS
CTS
RI
www.adtran.com
P/N 1200831L1
Description
Transmit Positive
Transmit Negative
Receive Positive
Unused
Receive Negative
Unused
Description
Data Carrier Detect (output)
Receive Data (output)
Transmit Data (input)
Data Terminal Ready (input)
Signal Ground
Data Set Ready (output)
Request to Send (input)
Clear to Send (output)
Ring Indicate (output)
