NetVanta 5305 Hardware Installation Guide

Installing the NetVanta VPN Accelerator Card (included in P/N 4200368L1)

The optional NetVanta VPN Accelerator card plugs into a 32-bit PCI slot and is designed to be used in the
NetVanta 5305 to provide encryption/decryption and security acceleration services for the host processor. The
card is a 1U-high PC card with gold fingers to interface to a 3.3 V keyed PCI connector. It provides the
following security services to the host processor: DES, 3DES, AES, SHA-1, MD5, and random number
generation. The card is powered from the +3.3 V rail of the PCI Bus, and the power consumption of the card
will not exceed 2 watts.
The AOS Enhanced Feature Pack software is required to take advantage of the VPN
acceleration features of this card.
The NetVanta VPN Accelerator card is intended to be installed only by qualified service
personnel.
Step
1 Remove power from the unit.
2 Use a screwdriver to take the screws out of the system controller module. Remove the module.
3 Gently slide the accelerator card into the PCI slot as shown. The card is keyed to fit into the slot
only one way. To avoid damaging the card pins, do not use excessive force.
4 Slide the system controller module into the controller slot until the module is firmly positioned
against the chassis.
5 Secure the screws at both edges of the module. Tighten with a screwdriver.
6 Restore power to the unit.
61200990L1-34N
Instructions for Installing the VPN Accelerator Card
Copyright © 2010 ADTRAN, Inc.
Action
Unit Installation
31
