APPENDIX A. PIN ASSIGNMENTS

The following tables provide the pin assignments for the NetVanta 5305 System controller and option
modules.

Controller Module Pinouts

Table A-1. 10/100Base-T Ethernet Port Pinouts

Pin Name
1 TX1
2 TX2
3 RX1
4, 5 —
6 RX2
7, 8 —

Table A-2. CONSOLE Port (DCE) Pinouts

Pin Name
1 DCD
2 RD
3 TD
4 DTR
5 SG
6 DSR
7 RTS
8 CTS
9 RI
Connection directly to an external modem requires a crossover cable.
61200990L1-34N
Description
Transmit Positive
Transmit Negative
Receive Positive
Unused
Receive Negative
Unused
Description
Data Carrier Detect (output)
Receive Data (output)
Transmit Data (input)
Data Terminal Ready (input)
Signal Ground
Data Set Ready (output)
Request to Send - flow control (input)
Clear to Send (output)
Ring Indicate (output)
