July 2014

NetVanta 5305

Hardware Installation Guide

NetVanta 5305 AC System

NetVanta 5305 AC System (RoHS Compliant)

NetVanta 5305 AC System with Enhanced Feature Pack (RoHS Compliant)

NetVanta 5305 AC System with T3 Wide Module

NetVanta 5305 DC System

Enhanced Feature Pack (Hardware and Software) for IPsec VPN Upgrade

NetVanta 5305 System Controller Module (RoHS Compliant)

NetVanta T3 Wide Module

NetVanta HSSI Wide Module

NetVanta Octal T1/E1 Wide Module

NetVanta 5305 AC Power Supply, 120 VAC

NetVanta 5305 AC Power Supply, 240 VAC

NetVanta 5305 DC Power Supply

Need help?

Do you have a question about the 4200990G1 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADTRAN 4200990G1

Page 1 NetVanta 5305 Hardware Installation Guide 4200990L1 NetVanta 5305 AC System 4200990G1 NetVanta 5305 AC System (RoHS Compliant) 4200990G2 NetVanta 5305 AC System with Enhanced Feature Pack (RoHS Compliant) 4200992L1 NetVanta 5305 AC System with T3 Wide Module 4200995L1 NetVanta 5305 DC System...
Page 2 To the Holder of this Manual The contents of this manual are current as of the date of publication. ADTRAN reserves the right to change the contents without prior notice. In no event will ADTRAN be liable for any special, incidental, or consequential damages or for commercial losses even if ADTRAN has been advised thereof as a result of issue of this publication.
Page 3 NetVanta 5305 Hardware Installation Guide Conventions Conventions Notes provide additional useful information. Cautions signify information that could prevent service interruption or damage to equipment. Warnings provide information that could prevent injury or endangerment to human life. 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 4 These units contain no user-serviceable parts. They should only be serviced by qualified service personnel. Additional safety guidelines, such as Waste Electrical and Electronic Equipment (WEEE), are given in the document NetVanta Safety and Regulatory Information available online at http://supportforums.adtran.com. Save These Important Safety Instructions Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 5 Advance notification and the opportunity to maintain uninterrupted service are given. 4. If experiencing difficulty with this equipment, please contact ADTRAN for repair and warranty information. The telephone company may require this equipment to be disconnected from the network until the problem is corrected, or it is certain the equipment is not malfunctioning.
Page 6 EN 55022 Class A EN 55024 1200934L1 HSSI Wide Module FCC Part 15 Class A EN 55022 Class A EN 55024 1202368E1 VPN Accelerator Card FCC Part 15 Class A EN 55022 Class A EN 55024 Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 7 Denial of Service (DoS) attacks, loss or theft of data, and the unauthorized or illegal use of said equipment. ADTRAN OFFERS NO WARRANTIES, EITHER EXPRESSED OR IMPLIED, REGARDING THE PREVENTION, DETECTION, OR DETERRENCE OF TOLL FRAUD, NETWORKING ATTACKS, OR UNAUTHORIZED, ILLEGAL, OR IMPROPER USE OF ADTRAN EQUIPMENT OR SOFTWARE.
Page 9 Contents of ADTRAN Shipments ........
Page 15 Frame Relay or Point-to-Point Protocol (PPP) networks. The NetVanta 5305 has six modular slots for customizing solutions and runs with the ADTRAN Operating System (AOS). The NetVanta 5305 family includes the NetVanta 5305 chassis, AC power supply, and system controller.
Page 16 After unpacking the unit, inspect it for possible shipping damage. If the equipment has been damaged in transit, immediately file a claim with the carrier and contact ADTRAN Customer Service (refer to the Support page on the ADTRAN website at http://www.adtran.com/support).
Page 17 NetVanta 5305 Hardware Installation Guide Product Overview PRODUCT OVERVIEW Reviewing the Front Panel Design Figure 1 shows the NetVanta 5305 front panel. Figure 1. NetVanta 5305 (AC and DC versions) Front Panel Layout 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 18 Data is present on the module (i.e., for the T3 module, this indicates TD/RD data). No activity on the module. TEST (Slots 1 through 6) No test is running. Yellow (solid) Module is in test. Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 19 Accepts electrical EIA-232 input from a PC or modem for controlling the NetVanta 5305. • Operates at rates ranging from 9.6 kbps to 115.2 kbps. • Acts an input for either VT100 or PC control. 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 20 Table A-1 on page 33 for the 10/100Base-T Ethernet interface pinouts. The 10/100Base-T Ethernet ports provide the following: • Auto-sensing • Primary data port service • Secondary DMZ port service • Local management access Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 21 IEC 60950 • AS/NZS 60950 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 11.63-inch W x 8.63-inch D 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 22 IEC 60950 • AS/NZS 60950 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, noncondensing Physical • Dimensions: 5.63-inch W x 8.63-inch D Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 23 • IEC 60950 • AS/NZS 60950 Environmental • Operating Temperature: 0°C to 50°C • Storage Temperature: -20°C to 70°C • Relative Humidity: Up to 95 percent, noncondensing Physical • 5.63-inch W x 8.63-inch D 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 24 Framing: FAS/NFAS with optional CRC-4 • FE1 Line Rate: Channelized timeslot (in multiples of 64 kbps) • Input Signal: 0 to -30 dB (DS1) on all E1 interfaces (1 through 8) • Connector: RJ-48C Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 25 The Octal T1/E1 Wide Module is shipped with the T1/E1 mode switch (located on the circuit board) set to T1. If you require E1 functionality, use your thumbnail to slide the E1 mode switch to the position (as shown in the figure below). 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 26 ADTRAN unit to Ethernet cables that run outside the building, ADTRAN's Ethernet Port Protection Device (EPPD) (P/N 1700502G1) must be connected between the unit and the outside plant cable. Use of any Ethernet protector other than ADTRAN's for this purpose will void the user's warranty.
Page 27 Have an assistant hold the unit in position as you install two mounting bolts through the unit’s brackets and into the equipment rack using a #2 Phillips-head screwdriver. Proceed to the steps given in the Installing Modules on page 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 28 Secure the screws at both edges of the module. Tighten with a screwdriver. Connect the cables to the associated device(s). Complete the installation of remaining modules and unit as specified in the appropriate sections of this hardware installation guide. Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 29 A redundant AC power supply can be installed as a backup power supply for the system. Two redundant AC power supplies are available and can be purchased separately: a 120 VAC supply (P/N 1200840G1#120) and a 240 VAC supply (P/N 1200840G1#240). 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 30 The card is powered from the +3.3 V rail of the PCI Bus, and the power consumption of the card will not exceed 2 watts. The AOS Enhanced Feature Pack software is required to take advantage of the VPN acceleration features of this card. Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 31 ADTRAN’s Support Forum For details on the CLI, refer to the AOS Command Reference Guide. All other related documents are also available online on ADTRAN’s Support Forum. 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 33 Data Terminal Ready (input) Signal Ground Data Set Ready (output) Request to Send - flow control (input) Clear to Send (output) Ring Indicate (output) Connection directly to an external modem requires a crossover cable. 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
Page 34 HSSI LB - Loopback Circuit B — HSSI SG - Signal Ground 14-18 — — Unused — HSSI SG - Signal Ground 20-23 — Unused HSSI TM - Test Mode — HSSI SG - Signal Ground Copyright © 2014 ADTRAN, Inc. 61200990L1-34P...
Page 35 Receive data from the network - Ring 1 Receive data from the network - Tip 1 — Unused Transmit data toward the network - Ring Transmit data toward the network - Tip — Unused 61200990L1-34P Copyright © 2014 ADTRAN, Inc.
