4.4
The setting of the baud rate must be identical in all nodes on the system bus. The
maximum possible baud rate is based on the necessary overall line length of the sys-
tem bus. The baud rate is set via the parameter
possible line length.
A baud rate under 50 kBaud, as is defined according to CANopen, is not sensible for
the system bus as the data throughput is too low.
The maximum line lengths stated are guidelines. If they are made complete use of, a
calculation of the admissible length is to be done on the basis of the line parameters
and the bus driver (PCA82C250T).
4.5
A maximum of 63 slaves or frequency inverters with system bus can be operated on
the system bus. Each frequency inverter is given a node ID, which may only exist once
in the system, for its unambiguous identification. The setting of the system bus node
ID is done via the parameter
Thus, the system bus possesses a maximum number of 63 nodes (Network nodes),
plus one frequency inverter as a master.
Note:
06/05
06/05

Baud rate setting/line length

Operation mode
3 - 50 kBaud
4 - 100 kBaud
5 - 125 kBaud
6 - 250 kBaud
7 - 500 kBaud
8 - 1000 kBaud

Setting node address

Parameter
No. Description
900 Node-ID
With the factory setting of parameter
is deactivated for this frequency inverter.
Node-ID
If the
ter. Only one frequency inverter on the system bus may be defined as a
master.
Function
Transmission rate 50 kBaud
Transmission rate 100 kBaud
Transmission rate 125 kBaud
Transmission rate 250 kBaud
Transmission rate 500 kBaud
Transmission rate 1000 kBaud
Node-ID
900.
min.
-1
900 = 0 is set, the frequency inverter is defined as a mas-
Baud-Rate
903 and thus defines the
max. line length
1000 meters
800 meters
500 meters
250 meters
100 meters
25 meters
Setting
max. Factory setting
63 -1
Node-ID
900 = -1, the system bus
