4.11.5.3 Examples of virtual links
Example 1:
Control word
Parameter 950 = Source-No. 740
Parameter 955 = Source-No. 62
The control word of frequency inverter 1 is linked with the control word of frequency
inverter 2. In this way, both frequency inverters can be operated synchronously via
the remote control. The output of the reference value channel of frequency inverter 1
is laid onto the output of the ramp of frequency inverter 2. In this way, both frequency
inverters have a joint source of reference values and are given reference values in the
internal notation.
As an extension, a number of frequency inverters can also exist on the receiving side
(Rx), which are supplied simultaneously with data parallel.
The input links not used in the TxPDO1 of frequency inverter 1 are set to ZERO and is
thus not be served.
Example 2:
Example of a virtual link with transmission via the system bus:
40
40
Frequency inverter 1
Source
Input link
- No.
950
740
Output ref-
955
erence fre-
quency
channel 62
TxPDO1 Identifier 925
Parameter
TxPDO1 Boolean1 946
Parameter
RxPDO1 Identifier 924
system bus
Parameter
Start-clockwise 068
Parameter
TxPDO1
RxPDO1
Byte
0
1
2
3
4
5
6
7
Parameter 99 = Source-No. 704
Parameter 137 = Source-No. 709
385
Identifier
385
Identifier
Frequency inverter 2
Source
Target
Byte
- No.
0
704
Control input,
Control word
1
2
3
4
709
Ramp input,
Line set value
5
137
6
7
Inverter 1
71-S2IND
Source-No.
Inverter 2
700-RxPDO1 Boolean
Source-No.
99
06/05
06/05
