1
This documentation has been created with greatest care and has been extensively and
repeatedly checked. For reasons of clarity, we have not been able to take all detailed
information on all the types of the products and also not every imaginable case of
positioning, operation or maintenance into account. If you require further information
or if particular problems not treated extensively enough in the operating instructions
occur, you can obtain the necessary information via the local representation of the
company BONFIGLIOLI.
In addition, we would point out that the contents of these operating instructions are
not part of an earlier or existing agreement, assurance or legal relationship, nor are
they intended to amend them. All the manufacturer's obligations result from the pur-
chase contract in question, which also contains the completely and solely valid war-
ranty regulation. These contractual warranty provisions are neither extended nor lim-
ited by the implementation of these operating instructions.
The manufacturer reserves the right to correct or amend the contents and product
information as well as omissions without specific announcement and assumes no kind
of liability for damage, injuries or expenditure to be put down to the aforementioned
reasons.
1.1
Warning! BONFIGLIOLI VECTRON frequency inverters have high voltage levels dur-
1.2
Warning! The frequency inverters are electrical drive components intended for in-
4
4
General safety and application information
General information
ing operating, depending on their protection class, drive moving parts and
have hot surfaces.
In the event of inadmissible removal of the necessary covers, improper
use, wrong installation or operation, there is the risk of serious damage to
persons or property.
To avoid the damage, only qualified staff may carry out the transport,
installation, setup or maintenance work required. Comply with the stan-
dards EN 50178, IEC 60364 (Cenelec HD 384 or DIN VDE 0100),
IEC 60664-1 (Cenelec HD 625 or VDE 0110-1), BGV A2 (VBG 4) and na-
tional provisions. Qualified persons within the meaning of this principal
safety information are people acquainted with the erection, fitting, com-
missioning and operating of frequency inverters and the possible hazards
and in possession of qualifications matching their activities.
Proper use
stallation in industrial plant or machines. Commissioning and start of in-
tended operation are not allowed until it has been established that the
machine corresponds to the provisions of the EC machine directive
98/37/EEC and EN 60204. According to the CE sign, the frequency invert-
ers additionally fulfill the requirements of the low-voltage directive
73/23/EEC and the standards EN 50178 / DIN VDE 0160 and EN 61800-2.
Responsibility for compliance with the EMC directive 89/336/EEC is with
the user. Frequency inverters are available in a limited way and as com-
ponents exclusively intended for professional use within the meaning of
the standard EN 61000-3-2.
With the issue of the UL certificate according to UL508c, the requirements
of the CSA Standard C22.2-No. 14-95 have also been fulfilled.
The technical data and the information on connection and ambient condi-
tions can be seen from the rating plate and the documentation and are to
be complied with at all costs. The instructions must have been read and
understood before starting the work at the device.
06/05
06/05
