Surround - Contura C i5AN Installation Instruction

Surround

Only handle the stone with clean hands or gloves. Handle the
stone carefully so as not to damage fragile corners and edges.
The stone is a natural material, which means that there may
be certain irregularities and variations in its appearance.
Clean the stone with a damp cloth. Soapy water can be used
Sections 3 and 4:
Height 357 mm.
Section 2:
Height 426 mm
Section 1:
Height 450 mm.
13 mm
T20
if necessary. To avoid abnormally large gaps and uneven lines,
it is important that the stove and steel stand are straight and
stable. Adjust and align it carefully before hanging the stone.
During assembly, check that all the stone sections are straight
and that all stones are of a uniform height.
G
F
E
D
C
B
A
T25
Allen screw 4
GB
117
SURROUND
G
E
C
B
