- Page 1 Installation Instructions For use in GB and IE only C i4 FS www.contura.eu...
- Page 2 See rating plate on the stove Intended area of use Heating of rooms in residential buildings Fuel Wood / (Coal briquettes) MANUFACTURER Name NIBE AB / Contura Address Box 134, Skulptörvägen 10 SE-285 23 Markaryd, Sweden CHECKS According to AVCP System 3...
- Page 3 A warm welcome to the Contura family. We hope you will get a great deal of pleasure from your new stove. As a new owner of a Contura stove you have secured a product with timeless design and long service life. Contura also has combustion that is both environmentally friendly and efficient for the best heat production.
-
Page 4: Technical Data
Technical data General Chimney In this manual you will find instructions Note! The stove installation and connection about how your Contura i4 FS shall be to a chimney must be accomplished with Output 3-5 kW installed. Before you start the installation the current edition of Building Regulations. - Page 5 INSTALLATION DISTANCES Installation distance to walls Ci4 FS Classic Move the stove in position and check that the minimum installation minimum dimension as shown in the diagram. Always check that the distances given in the diagrams are met. The minimum distance in building has enough bearing capacity for the hearth, stove and chimney.
- Page 6 INSTALLATION DISTANCES Installation distance to walls Ci4 FS Modern Move the stove in position and check that the minimum installation minimum dimension as shown in the diagram. Always check that the distances given in the diagrams are met. The minimum distance in building has enough bearing capacity for the hearth, stove and chimney.
- Page 7 PREINSTALLATION Prior to installation...
-
Page 8: Supply Of Combustion Air
COMBUSTION AIR / ACCESSORY Supply of combustion air When a stove is installed in a room, the demand for air supply to the room increases. Air can be provided indirectly via a vent in the outer wall or via a duct from the outside that is connected to the stove. - Page 9 SMOKE CONTROL AREA Smoke control area In smoke control areas it is mandatory to stop the damper from closing completely. In other areas it´s optional. Ci4 FS Classic Ci4 FS Modern...
- Page 10 INSTALLATION Adjusting and connecting Adjusting the stove • Position the stove on the hearth plate. • Adjust the height of the four adjustable feet until the stove is horizontal. After the stove has been adjusted and positioned according to the installation distances, connection to the chimney is carried out. Put stove cement inside the flue connection and press the pipe into the connection.
- Page 11 REMOVAL Removing the loose components Fire bars Lift the fire bars straight up, clean the ash from the guide groove in the stove base plate before repositioning it in position. Fire box surround When sweeping, the smoke baffle must be lifted out, this can be done when one side has been dismantled.
- Page 12 NIBE AB · Box 134 · 285 23 Markaryd · Sweden www.contura.eu Contura reserves the right to change dimensions and procedures described in these instructions at any 811191 IAV Ci4 FS GB-2 time without special notice. The current edition can be 2014-05-07 downloaded from www.contura.eu...
